Hella Spade Terminal - 178042202

Name: Hella Spade Terminal - 178042202
SKU: 178042202
Availability: OutOfStock

HELLA Spade Terminal 178042202

Manufacturer: Hella

Manufacturer part number: 178042202

$0.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Make secure electrical connections with the HELLA Spade Terminal. Ideal for automotive and industrial wiring, it offers quick, reliable connectivity with easy installation. Built from high-quality materials for strong conductivity and corrosion resistance, this terminal ensures lasting performance. Trust HELLA for dependable electrical components that get the job done right.

Products specifications

Attribute name	Attribute value
Cross Section [mm²] from	4
California Proposition 65 Required	No
Cross Section [mm²] to	6
Temperature range from [°C]	-40
Temperature range from [°F]	-40
Assy/Disassy by Qualified Personnel Required!	.
Length (in.)	0.98
Temperature range to [°C]	105
Temperature range to [°F]	221.00
Length [mm]	25
Bore Diameter [mm]	4.3
Bore Ø [mm]	4.3
DIN/ISO Standard	46237
Current Strength to [A]	48
Quantity	50
Voltage to [VDC]	600
Container Type	Blister Pack
Material	Copper
Plug Type ID	M4
Insulation Material	Nylon
Plug Type	Ring Connector
Version	Standard
Surface	Tin-Plated
Color	Yellow
Country of Origin	CN
