Hella Accessory Horn - 003399801

Name: Hella Accessory Horn - 003399801
SKU: 003399801
Availability: InStock

Manufacturer: Hella

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

HELLA Accessory Horn 003399801

Products specifications

Attribute name	Attribute value
Homologation	ECE-R28
Bracket	M8 Mounting Screw
Set includes	(1) High-Tone Unit, Mounting Brackets, Step-by-Step Mounting Instructions
IP Rating	IP65
Temperature range to [°C]	60
California Proposition 65 Required	No
Grade Type	Standard Replacement
Temperature range from [°C]	-40
Temperature range from [°F]	-40
Assy/Disassy by Qualified Personnel Required!	.
Sound Level [dB(A)]	118
Decibel Rating [dB]	118.00
Voltage [VDC]	12.00
Diameter (mm)	123
Width [mm]	125
Overall Height [mm]	135
Temperature range to [°F]	140
Terminal Quantity	2
Quantity	2
Depth (in.)	3.35
Frequency Range [Hz]	300
Frequency range from [Hz]	300
Diameter (in)	4.84
Width [in]	4.92
Overall Height [in]	5.31
Power consumption [A]	5.5
Frequency range to [Hz]	500
Wattage (W)	66
Depth [mm]	85
Terminal Type	Blade
Mount Type	Bracket Mounting
Test Mark	ECE
Registration Type	ECE Approved
Operating Mode	Electric
Mounting Type	Flat Plug-in Connector
Quantity Unit	Kit
Signal	Loud Tone
ECE Regulation	R28
Color	Red/Black
Housing Color	Red / Black
Mounting Hardware Included	Yes
Mounting Bracket Included	Yes
