Hella Horn - 002768551

Name: Hella Horn - 002768551
SKU: 002768551
Availability: OutOfStock

Disc Type High-Tone, 12 V, 400 Hz with Bracket

Manufacturer: Hella

Manufacturer part number: 002768551

$0.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Make your presence known with the HELLA Horn. Designed for loud, clear sound output, it ensures you’re heard in any situation for added safety. Built tough to withstand harsh conditions, this horn delivers reliable performance and easy installation. Trust HELLA for durable, high-quality components that keep you safe on the road.

Products specifications

Attribute name	Attribute value
Temperature range to [°C]	60
Frequency range to [Hz]	400
Diameter [cm]	11.2
Diameter (in)	4.41
Bracket	M10 Mounting Screw
Single Includes	(1) High-Tone Disc Horn, Mounting Brackets, Step-by-Step Mounting Instructions
California Proposition 65 Required	No
Homologation	ECE-R28
Measurements [cm]	5.3 x 12.9
Voltage	12.00
Connector Quantity	1
Terminal Quantity	2
Mounting Bracket Included	Yes
Temperature range from [°C]	-40
Temperature range to [°F]	140
Depth (in.)	2.09
Frequency Range [Hz]	400
Overall Height [in]	5.08
Depth [mm]	53
Power consumption [A]	6
Wattage (W)	72
Color	Black, Gray
Housing Color	Black / Gray
Terminal Type	Blade
Mount Type	Bracket Mounting
Registration Type	ECE Approved
Test Mark	ECE-R28
Operating Mode	Electric
Mounting Type	Flat Plug-in Connector
Signal	High Tone
ECE Regulation	R28
Grade Type	Standard Replacement
Supplementary Article/Supplementary Info 2	with E Quality Seal
IP Rating	X9K
Mounting Hardware Included	Yes
Temperature range from [°F]	-40
Assy/Disassy by Qualified Personnel Required!	.
Quantity	1
Diameter (mm)	112
Sound Level [dB(A)]	116
Voltage [VDC]	12
Overall Height [mm]	129
Decibel Rating	116.00
Country of Origin	IN
