Hella Horn - 007424011

Name: Hella Horn - 007424011
SKU: 007424011
Availability: OutOfStock

Trumpet High-Tone, 12 V, 500 Hz with Bracket

Manufacturer: Hella

Manufacturer part number: 007424011

$0.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Make your presence known with the HELLA Horn. Designed for loud, clear sound output, it ensures you’re heard in any situation for added safety. Built tough to withstand harsh conditions, this horn delivers reliable performance and easy installation. Trust HELLA for durable, high-quality components that keep you safe on the road.

Products specifications

Attribute name	Attribute value
Frequency range to [Hz]	500
Includes	(1) Low-Tone Trumpet Horn, Mounting Brackets, Step-by-Step Mounting Instructions
Bracket	M8 Mounting Screw
Homologation	ECE-R28
California Proposition 65 Required	No
Voltage	12.00
Connector Quantity	1
Terminal Quantity	2
Mounting Bracket Included	Yes
Temperature range from [°C]	-40
Temperature range from [°F]	-40
Assy/Disassy by Qualified Personnel Required!	.
Quantity	1
Width [mm]	109
Sound Level [dB(A)]	110
Voltage [VDC]	12
Temperature range to [°F]	176
Depth (in.)	3.15
Overall Height [in]	3.5
Width [in]	4.29
Frequency Range [Hz]	500
Power consumption [A]	6
IP Rating	6K9K
Wattage (W)	72
Depth [mm]	80
Temperature range to [°C]	80
Overall Height [mm]	89
Terminal Type	Blade
Mount Type	Bracket Mounting
Test Mark	ECE
Registration Type	ECE Approved
Operating Mode	Electric
Mounting Type	Flat Plug-in Connector
Signal	High Tone
ECE Regulation	R28
Color	Red/Black
Housing Color	Red / Black
Grade Type	Standard Replacement
Supplementary Article/Supplementary Info 2	with E Quality Seal
Mounting Hardware Included	Yes
Decibel Rating	110.00
Country of Origin	IN
