Hella Spade Terminal - 178042102

Name: Hella Spade Terminal - 178042102
SKU: 178042102
Availability: OutOfStock

HELLA Spade Terminal 178042102

Manufacturer: Hella

Manufacturer part number: 178042102

$0.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Make secure electrical connections with the HELLA Spade Terminal. Ideal for automotive and industrial wiring, it offers quick, reliable connectivity with easy installation. Built from high-quality materials for strong conductivity and corrosion resistance, this terminal ensures lasting performance. Trust HELLA for dependable electrical components that get the job done right.

Products specifications

Attribute name	Attribute value
California Proposition 65 Required	No
Temperature range from [°C]	-40
Temperature range from [°F]	-40
Assy/Disassy by Qualified Personnel Required!	.
Cross Section [mm²] from	1.5
Quantity	100
Temperature range to [°C]	105
Length [mm]	19.7
Cross Section [mm²] to	2.5
Temperature range to [°F]	221.00
Current Strength to [A]	27
Bore Diameter [mm]	3.6
Bore Ø [mm]	3.6
DIN/ISO Standard	46237
Voltage to [VDC]	600
Container Type	Blister Pack
Color	Blue
Material	Copper
Plug Type ID	M3
Insulation Material	Nylon
Plug Type	Ring Connector
Version	Standard
Surface	Tin-Plated
Country of Origin	CN
