ICON Vehicle Dynamics Coilover Set - 58711-CB

Name: ICON Vehicle Dynamics Coilover Set - 58711-CB
SKU: 58711-CB
Price: 1996.75 USD
Availability: OutOfStock

96-04 TACOMA 2.5 VS RR COILOVER KIT W PROCOMP 6"

Manufacturer: ICON Vehicle Dynamics

Manufacturer part number: 58711-CB

Old price: $2,096.59

Price: $1,996.75

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

1996-2004 TACOMA 2.5 VS REMOTE RESERVOIR COILOVER KIT W/ PROCOMP 6" LIFT

Note: Coilover length optimized for use with ProComp 6" lift but may also be compatible with others

Products specifications

Attribute name	Attribute value
AAP_UDA_12	EA
AAP_UDA_22	1
AAP_UDA_4	55
Service Parts	191016 - 7.5" FINNED RESI UPGRADE KIT, 252011 - 2.5 PIGGYBACK/REMOTE RESI/BYPASS REBUILD KIT, 254100G - 1 GALLON ICON PERFORMANCE SHOCK OIL, 611067 - TACOMA/FJ/4RNR LOWER CO BRG/SPCR KIT, 611019 - COILOVER HARDWARE KIT PAIR, 257339 - 7/8 SHAFT 13.25 OAL, 9.00 TRAVEL, 252001 - 2.5 FIXED SPANNER WRENCH, 252003 - SEAL INSTALL TOOL 2.5/3.0, 252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0)
Shaft Diameter	0.875
Shock Absorber Body End Measuring Point	Top of Upper Mount Plate
Shock Absorber Rod End Measuring Point	CENTER OF EYELET
Spring Color	Black
Spring Material	Steel
Spring Rate Type	Linear
Travel Length	4.67
Upper Mount Type	Mounting Plate
Valving Type	Digressive
Active or Passive Suspension	Passive
Add-On Part	252012 - -4 TO -10 HOSE SHIELD KIT, 198001 - BILLET SPANNER WRENCH KIT, 198000 - 2 PIN COILOVER SPANNER WRENCH KIT, 191003 - ICON SHORT 2.5 COIL WRAP W/LOGO PAIR (11.25-12.25)
Adjustable Compression	No
Adjustable Damping	No
Adjustable Rebound	No
Adjustable Ride Height	Yes
Assembled	Yes
Body Diameter	2.5
California Prop 65 Warning	Yes
Dust Shield Included	No
Extended Length	26.27
Front Spring Rate	650
Gas Charged	Yes
Grade Type	Performance
Includes Bump Stop	No
Internal Construction Type	Single Tube
Lower Mount Type	Eyelet
Material	Steel, Aluminum
Remote Reservoir	Yes
Reservoir Style	Remote
Self-Leveling	No
Damping Type	Oil
Cylinder Material	Steel
Cylinder Finish	Cadmium Plated
Cylinder Color	Silver
Compressed Length	21.62
Coil-Over Springs Included	Yes
California Proposition 65	WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Country of Origin	US
Condition	New
