AAP_UDA_12
|
EA |
|
AAP_UDA_22
|
1 |
|
AAP_UDA_4
|
55 |
|
Active or Passive Suspension
|
Passive |
|
California Prop 65 Warning
|
Yes |
|
California Proposition 65
|
WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm. |
|
Coil-Over Springs Included
|
Yes |
|
Dust Shield Included
|
No |
|
Add-On Part
|
252012 - -4 TO -10 HOSE SHIELD KIT, 98500DJ - 04-20 F150/14-UP EXPEDITION TUBULAR UCA DJ KIT, 97720CP - 09-24 F150 2/4WD 04-08 F150 4WD REAR 2.5 VS PB CDCV PAIR, 198001 - BILLET SPANNER WRENCH KIT, 198000 - 2 PIN COILOVER SPANNER WRENCH KIT, 98505DJ - 09-20 F150/14-20 EXPEDITION BILLET UCA DJ KIT, 191009 - ICON LONG 2.5 COIL WRAP W/LOGO (14.5-15.5) |
|
Adjustable Compression
|
Yes |
|
Adjustable Damping
|
Yes |
|
Adjustable Height
|
Yes |
|
Adjustable Rebound
|
No |
|
Adjustable Ride Height
|
Yes |
|
Assembled
|
Yes |
|
Body Diameter
|
2.5 |
|
Compressed Length
|
18.12 |
|
Cylinder Color
|
Silver |
|
Cylinder Finish
|
Cadmium Plated |
|
Cylinder Material
|
Steel |
|
Damping Adjustment Type
|
Manual |
|
Damping Type
|
Oil |
|
Extended Length
|
23.48 |
|
Front Spring Rate
|
600 |
|
Gas Charged
|
Yes |
|
Grade Type
|
Performance |
|
Includes Bump Stop
|
Yes |
|
Internal Construction Type
|
Single Tube |
|
Lower Mount Type
|
Bar Pin |
|
Material
|
Aluminum, Steel |
|
Maximum Lift
|
2.63 |
|
Maximum Ride Height Raising Distance
|
2.63 |
|
Minimum Lift
|
1.75 |
|
OEM Wheels & Tires Fitment
|
Yes |
|
Recommended Aftermarket Tires
|
33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required) |
|
Recommended Aftermarket Wheels
|
ICON Alloys - 20x9" w/ 5.625” Backspace / 16mm Offset, ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset, ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset |
|
Remote Reservoir
|
Yes |
|
Reservoir Style
|
Remote |
|
Self-Leveling
|
No |
|
Service Parts
|
257337 - 7/8 SHAFT 11.25 OAL, 7.00 TRAVEL, 191016 - 7.5" FINNED RESI UPGRADE KIT, 611019 - COILOVER HARDWARE KIT PAIR, 252003 - SEAL INSTALL TOOL 2.5/3.0, 252001 - 2.5 FIXED SPANNER WRENCH, 252002 - UNIVERSAL SPANNER WRENCH (2.0/2.5/3.0), 252011 - 2.5 PIGGYBACK/REMOTE RESI/BYPASS REBUILD KIT, 254100G - 1 GALLON ICON PERFORMANCE SHOCK OIL |
|
Shaft Diameter
|
0.875 |
|
Shock Absorber Body End Measuring Point
|
Top of Upper Mount Plate |
|
Shock Absorber Rod End Measuring Point
|
Flat on Bar Pin |
|
Spring Color
|
Black |
|
Spring Material
|
Steel |
|
Spring Rate Type
|
Linear |
|
Travel Length
|
5.37 |
|
Upper Mount Type
|
Mounting Plate |
|
Valving Type
|
Digressive |
|
Country of Origin
|
US |
|
Condition
|
New |
