McLeod Transmission Clutch and Flywheel Kit - 651001-00-04

Name: McLeod Transmission Clutch and Flywheel Kit - 651001-00-04
SKU: 651001-00-04
Price: 1295.00 USD
Availability: OutOfStock

Mag Force: 1 Disc: Pin Drive: Chevrolet 1955-85 SBC: 1-1/8 x 10: 153T

Manufacturer: McLeod

Manufacturer part number: 651001-00-04

Old price: $1,618.75

Price: $1,295.00

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Mag Force - These Clutches Are the Perfect Choice for Racers Looking for A Lightweight, High Torque Capacity Unit. They Are Designed to Be Used for Oval Track, Road Racing and Dry Lakes Applications. These Units Are Offered in Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations to Meet the Harshest Needs in The Industry. These Units Rely on A Pin Drive Actuation System Where the Floater Plate Slides On 6 Evenly Spaced Pins for Quick Release in A Racing Application. Our Mag Force Units Also Offer Bolt on External Balance Weights for Most Applications.

Note: Counter Weight Kit if Required 560222 (sold separately)

Products specifications

Attribute name	Attribute value
Disc Diameter (in.)	8.000
Input Shaft Diameter (in.)	1.125
Input Spline Quantity	10
Disc Material	Sintered Iron
Disc Style	Full face
Hub Style	Solid
Clutch Disc Quantity	1
Pressure Plate Style	Diaphragm
Clutch Usage	Performance
Hardware Included	Yes
Alignment Tool Included	Yes
Pilot Bushing Included	No
Throwout Bearing Included	No
Flywheel Included	Yes
Flywheel Material	Billet aluminum
Ring Gear Tooth Quantity:	153-tooth
Crankshaft to Flywheel Bolt Quantity	6-bolt
Engine Balance	Internal
Quantity	Sold as a Kit
Counter Weight Kit if Required	560222 (sold separately)
Rear Main Seal Style	2 Piece
Note	also fits 1991-2022 crate BBC 1pc Seal large crank flange
Country of Origin	US
Condition	New
