Proform Carburetor - 67201

Name: Proform Carburetor - 67201
SKU: 67201
Price: 643.67 USD
Availability: OutOfStock

Carburetor - 850 CFM

Manufacturer: Proform

Manufacturer part number: 67201

$643.67

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Engine Carburetor

Products specifications

Attribute name	Attribute value
Primary Power Valve (Hg)	4.5
Base Plate Material	Billet Aluminum
Booster Style	Down-Leg Boosters
Series	Race Series
Secondaries	Mechanical Secondaries
Calibration	Universal
PartType	Carburetor
Metering Block Material	Billet Aluminum
Main Body Material	Lightweight Aluminum
Category	Carbs
Throttle Linkage	Universal
Fuel Inlet	Dual
Fuel	Gasoline
Flange Style	Square Bore
Emissions	49 State Legal
EGR	Without EGR
CFM:	850 CFM
Fuel Inlet Thread	7/8-in. x20
Air Bleeds Included	Yes
Air Bleed Material	Brass
Spacer Included	No
Small Venturi Diameter	1.75
Mounting Hole Quantity	4
Mounting Hole Diameter	0.25
Mounting Hardware Included	No
Marine Approved	No
Main Venturi Diameter	1.875
Linkage Attached	Yes
Grade Type	Performance
Gasket Or Seal Included	Yes
Float Material	Nitrophyl
Flange Shape	4150 & 8090
Choke Type	Manual
Center Hung Floats	Yes
Body Material	Aluminum
Body Height	3.25
Body Color	Silver
Base Width	5.25
Base Length	5.25
Barrel Quantity	4
Air Cleaner Flange Diameter	0.25
Adjustable Float Level	Yes
Secondary Jet Diameter	0.102
Primary Jet Diameter	0.087
Street Legal	Yes
Flange Type	Square/4150
Secondary Barrel Type	Mechanical
Prop 65 Yes/No	Yes
Prop 65 (C, R or CR)	CR
Feature/Benefit	Lightweight Aluminum Construction
Prop 65 - Short Label	WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Idle/High Speed Air Bleed Sizes	70 / 35
Prop 65 Long Label	WARNING: Handling passenger or off-highway motor vehicle parts can expose you to chemicals such as phthalates and lead, which can cause cancer and reproductive harm. To minimize exposure, service the vehicle in a well-ventilated area, wear gloves, and wash your hands. For more information see P65Warnings.ca.gov/auto-parts.
Needle & Seat	120
Prop 65 Warning Label	Proposition 65 Warning.JPG
Ford Kickdown Bracket Included	No
Discharge Nozzle Size (Primary / Secondary)	.033 in. / .033 in.
Secondary Main Jet Size	87.5 / .099
Fuel Line Inlet Distance	9-11/16 inch
Air Bleed Size (Inner High Speed)	35 / 35
Primary Main Jet Size	78 / .084
Choke	No Choke
Number of Barrels	4
Air Bleed Size (Outer Idle)	70 / 70
