SBC Engine Block 1PC 9.025 Deck 4.000 Bore

Name: SBC Engine Block 1PC 9.025 Deck 4.000 Bore
SKU: BPP12110352
Price: 3785.43 USD
Availability: OutOfStock

Manufacturer: BluePrint Engines

Manufacturer part number: BPP12110352

Old price: $3,999.00

Price: $3,785.43

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Engine - Bare Block - 4.000 in Bore - 9.025 in Deck - 350 Main - 4-Bolt Main - 1-Piece Seal - Billet Steel Main Caps - Cast Iron - Natural - Small Block Chevy - Each

Manufacturer Part #: BPP12110352

Products specifications

Attribute name	Attribute value
Starter	OEM
Stroke (Max)	Cast in clearance 3.875"
Product Type	Engine
Timing Cover	OEM
Material	Cast Iron
Sub Type	Bare Block
Weight With Main Caps	170-190lbs
Finish	Natural
Cylinder Bore (Max)	4.250"
Unit	Each
Cam Bearing Bore Id	2.000"+/- .001"
Cam Bearings	Durabond GMP-8
Camshaft Position	OEM
Specifications	4.000 in Bore, 9.025 in Deck, 350 Main, 4-Bolt Main, 1-Piece Seal, Billet Steel Main Caps, Small Block Chevy
Cam Drive / Timing Set	OEM equivalent
Cam Retaining Plate	OEM
Cubic Inch (Max)	454
Cylinder Wall Thickness	.230" Nominal @ Max Bore
Water Jacket Style	Siamese
Cylinder Skirt Length	5.800" Nominal
Deck Height	9.025" +.005" / -.000"
Deck Thickness:	.600" Nominal
Freeze / Core Plugs	1-5/8" x 10
Head Bolt Threads	7/16-14 UNC
Lifter Bores	.8437" +/- .0003"
Lifter Retainer (If Not Using Tie Bar Lifters)	OEM W/Roller Provisions
Main Bearing Bore (Line Honed)	350 Main - 2.6402" - 2.6410"
Main Bearing Caps	Billet Steel 4-Bolt splayed
Main Cap Bolts	7/16-14 Inner / 3/8-16 splayed
Main Fastener Tensile Strength	180,000 to 210,000 PSI
P1 Main Stud Kit P/N:	TBD
Arp Main Stud Kit P/N	TBD
Material (Block)	EN-GJL-250 Iron
Oil System	Priority Main
Oil Pump	OEM
Oil Filter	OEM
Oil Pan	OEM
Fuel Pump	OEM
Rear Main Seal	1 piece
Quantity	Sold Individually
Prop 65 Y/N Flag	Yes
Cylinder Bore (Rough)	3.995" to 3.997"
Prop 65 - Short Label	WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Country of Origin	US
Condition	New
