Spicer Drive Shaft Midship Stub Shaft - 3-53-1371

Name: Spicer Drive Shaft Midship Stub Shaft - 3-53-1371
SKU: 3-53-1371
Availability: InStock

DRIVE SHAFT MIDSHIP STUB SHAFT

Manufacturer: Spicer

Manufacturer part number: 3-53-1371

$0.00

Qty:

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

Demand Genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non-genuine parts simply cannot deliver.

Products specifications

Attribute name	Attribute value
Series	1310-1410
Material	Steel
Style	1
Prop 65	NO
Spline O.D.	1.3750
Spline Length (L) In	4.438
Bearing Diameter (Min)	1.3779
For Use With	Outboard Slip Yoke
Shoulder Diameter (B) In.	1.688
Shoulder Length (G) In.	0.812
Spline End To Brg Shoulder (Y)	6.781
Bearing Diameter Length	1.56
Number of Splines	16
Spline End To Weld (K) In.	7.031
Bearing Diameter (Max)	1.3784
Bearing Diameter (C) In.	1.378
Butt Diameter	2.845
Fits Tube Wall	0.083
Involute	N
Fits Tube Diameter	3
Country of Origin	MX
Condition	New
