Top Street Performance Ignition Coil - JM6924R

Name: Top Street Performance Ignition Coil - JM6924R
SKU: JM6924R
Price: 30.26 USD
Availability: OutOfStock

Compact Red Square E-Core Ignition Coil

Manufacturer: Top Street Performance

Manufacturer part number: JM6924R

Old price: $41.16

Price: $30.26

Ship to

Shipping Method

Name

Estimated Delivery

Price

No shipping options

TSP's new compact e-core ignition coil puts out 40,000 volts, giving you a much hotter and larger spark to burn fuel more efficiently and provide smooth acceleration thoroughout the entire RPM band. It's small design allows for easy mounting, and the brass terminal ensures maximum conductivity.

Application: Universal

Note: Intended for high-performance distributor ignition set-ups

Products specifications

Attribute name	Attribute value
Coil Color	Red
Coil Shape	Square
Coil Style	Compact E-core
Inductance	6.9 mH
Max Voltage	40,000 V
Peak Current	300 mA
Primary Resistance	0.355 ohms
Prop 65 - Short Label	prop65_warning.jpg
Prop 65 (C, R or CR)	CR
Prop 65 Flag	Yes
Secondary Resistance	4,400 ohms
Spark Duration	200 uS
Turn Ratio	70
